W**elength Range

190 nm - 20 μm

190 nm - 20 μm

190 nm - 20 μm

190 nm - 20 μm

Optical Power Range

10 μW - 1 W (3 Wb)

100 μW - 5 W

2 mW - 10 W (20 Wb)

2 mW - 10 W (20 Wb)

Input Aperture Size

?10 mm

?10 mm

?15 mm

?25.4 mm

Active Detector Area

10 mm x 10 mm

10 mm x 10 mm

?15 mm

?27 mm

Max Optical Power Density

500 W/cm2 (**g.)

1.5 kW/cm2 (**g.)

1.5 kW/cm2 (**g.)

1.5 kW/cm2 (**g.)

Linearity

±0.5%

±0.5%

±0.5%

±0.5%

Resolutionc

1 μW

5 μW

100 μW

100 μW

Measurement Uncertaintyd

±3% @ 1064 nm

±3% @ 1064 nm

±3% @ 1064 nm

±3% @ 1064 nm

±5% @ 190 nm - 10.6 μm

±5% @ 250 nm - 17 μm

±5% @ 250 nm - 17 μm

±5% @ 250 nm - 17 μm

Response Timee

1.1 s

1.1 s

0.6 s

0.6 s

Cooling

Convection (Passive)

Convection (Passive)

Housing Dimensions

33.0 m x 43.0 mm x 15.0 mm

40.6 mm x 40.6 mm x 16.0 mm

50.8 mm x 50.8 mm x 35.0 mm

50.8 mm x 50.8 mm x 35.0 mm

(Without Adapter)

(1.30" x 1.69" x 0.59")

(1.60" x 1.60" x 0.63")

(2.00" x 2.00" x 1.38")

(2.00" x 2.00
